Takeuchi TB153FR User Manual

49
CONTROLS
Automatic Decel. Button
< TB180FR >
Pressing this button to the ON position will
cause the lamp to light and will activate the
deceleration function. Use of the deceleration
button will not be possible at this time. After
about 4 seconds with the control levers set
to neutral, the engine speed will automatically
drop to Low idling to reduce fuel
consumption. Moving the control levers will
cause the speed to return to the original
engine speed.
Throttle Controller < TB180FR >
This controls the engine speed.
(A) .... Low idling
(B) .... Middle speed
(C) .... Maximum speed
Switches
Horn Button
Press the button on the right operating lever
to blow the horn.
Decel. Button
WARNING
Set the operating and travel levers to
neutral before operating the decel. button.
The machine’s operating speed will
change abruptly if the switch is operated
while the levers are engaged.
Press the button on the right operating lever
to lower the engine speed to low idling.
Press the button again to return to the engine
speed set with the throttle controler.
Supplement: The one-touch decelerator is
a device for lowering the engine speed and
reducing fuel consumption when little engine
output is required, for example when the
operating and travel levers are in neutral.
N0B019

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
