TROUBLESHOOTING
If a Warning Lamp Flashes
If an alarm is sounded or a warning lamp starts flashing during operation, park the machine
in a safe place and perform the procedures described below.
OSOB080
C4B012
G4B009
Warning lamp Lamp name Procedure
The coolant temperature has risen irregularly and the
engine is overheating.
Refer to page 163 “If the Engine Overheats”.
Engine
emergency
lamp
A problem has occurred in the engine lubrication system
or cooling system.
¡ When there is a problem in the engine lubrication
system or coolant level, the engine oil pressure /
coolant level warning lamp flashes simultaneously.
¡ When the coolant water temperature has risen
irregularly, the coolant temperature warning lamp
flashes simultaneously.
For the procedures, refer to the respective warning lamps
below.
Battery charge
warning lamp
There is a problem with the fan belt or charger. Inspect
the fan belt for slack or breakage and adjust as necessary.
If the lamp continues flashing after maintenance, there
is a problem with the charger. Consult a Takeuchi sales
or service outlet.
Refer to page 127 “Inspecting and Adjusting the Fan Belt”.
Engine oil
pressure/
coolant level
warning lamp
Inspect the engine oil level or coolant level. If the lamp
is flashing even though the level is normal or if it
continues flashing after oil or coolant are supplied,
consult a Takeuchi sales or service outlet.
Refer to page 120 or 121 “Inspecting and replenishing
the coolant” or “Inspecting and Replenishing the
Engine Oil”.
Coolant
temperature
warning lamp
Air cleaner
warning lamp
The air cleaner filter is clogged.
Refer to page 134 “Cleaning the Air Cleaner”.
C
G
4B
0
1
0
L3J004

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
