Takeuchi TB153FR User Manual

69
OPERATION
Before Starting Operation
Before Starting the Engine
1. Adjust the seat for a comfortable operating
position.
2. Fasten the seat belt.
3. Check that the safety lock lever is in the
locked position.
4. Check that all the levers and pedals are
in the neutral position.
5. Insert the key into the starter switch, turn
it to the ON position, then perform the
following inspection :
¡All the warning lamps flash and an
alarm is sounded for 2 seconds. The
meters also start functioning. After 2
seconds, only the battery charge
warning lamp (4) and engine oil
pressure / coolant level warning lamp
(2) flash, and the other lamps turn off.
¡< TB180FR > : Check that the decel. lamp
(8) is lit.
¡Turn the light switch to check that the
boom light, front light and meter light
turn on.
¡Check the fuel level.
If a lamp does not light or the alarm is not
sounded, the bulb may be burnt out or a wire
may be damaged. Contact a Takeuchi sales
or service outlet for repairs.
S2B015
PREHEAT
OFF
ON
START
E4D002

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
