Takeuchi TB153FR User Manual

52
CONTROLS
Switches
Light Switch
When this switch is turned while the starter
switch is at ON, the lights turn on as follows :
O ...... Off
I ....... Meter light, front light and boom light
turn on.
L3B028
L3B029
PUSH
Wiper Switch (Cab)
IMPORTANT: If no washer fluid is
discharged, do not operate the washer.
Doing so may damage the pump.
IMPORTANT: Operating the wiper with no
moisture on the windshield will scratch
the glass. Apply water or washer fluid
when operating the wiper.
IMPORTANT: In cold seasons, the wiper
blade may freeze to the glass. Operating
the wiper forcibly may damage the wiper
motor.
O ............ Off
I ............. Wiper operates.
PUSH ..... Washer fluid is squirted from the
nozzle while pressed, and stops
when released.

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
