SAFETY
Safety Signs (Decals)
22. No.03993-00500
Position of Hoisting
20. No.03593-06700
Hydraulic oil
19. No.03593-06600
Diesel Fuel
21. No.08810-31549
Tie down point
9. No.03793-37300
10. No.03593-07400
11. No.03593-47010
12. No.03393-68100
13. No.03393-75040
14. No.03393-75050
15. No.05693-21980
18. No.05693-53810
WARNING
03793-37300
If the platform is raised or lowered while the
engine is running, the machine may start
moving.Be sure to stop the engine first.
If you need to run the engine while the
platform is raised, follow the instructions
below.
(Refer to the Instruction Manual.)
1. Place the machine on a stable, level
surface, and stop the engine.
2. Lock the operating lever.
3. Tilt-up the platform.
4. Insert the stopper to prevent platform from
dropping.
5. Make sure that all levers and pedals are in
neutral positions.
6. Push the throttle lever fully forward.
(Low idling)
7. Start the engine.
8. After inspection and maintenance is
compiete, stop the engine,
CAUTION
03593-07400
STOP ENGINE
BEFORE OPENING
WARNING
03593-47010
THIS EXCAVATOR
MUST NOT BE USED
AS A CRANE
WARNING
03393-68100
WHEN BUCKETS WIDER THAN STANDARD
ARE FITTED TO THIS MACHINE,
CAB(CANOPY)DAMAGE MAY OCCUR WHEN
FULL RIGHT HAND BOOM OFFSET IS USED.
CAUTION
03393-75040
DO NOT USE ETHER
USAGE OF ETHER FOR STARTING
PURPOSES MAY CAUSE INTERNAL
ENGINE DAMAGE.
CAUTION
03393-75050
HYDRAULIC TANK MUST REMAIN
PRESSURIZED TO AVOID DAMAGE
TO PUMPS.
WARNING
05693-21980
Engine may be HOT
05693-53810
Setting this switch to the “OFF”
position will shut down all of
the electrical circuits and the
memory of the radio preset
tuning buttons will be deleted.
CAUTION
8. No.03593-13700
WARNING
This machine,if improperly operated or
maintained can cause bodily harm,or even
DEATH.
Read and understand the owners manual
supplied with this machine before operating.
Keep all safety devices in place and
functional.
Do not operate the machine unless the seat
belt is properly fastened around you.
Follow the instructions in the Operator’s
Manual when hoisting the machine or
fastening it to the transport vehicle.
03593-13700
1 -
2 -
3 -
4 -
5 -
16. No.03993-52302
WARNING
03993-52302
DO NOT ENTER
INTO PINCH AREA.
Diesel Fuel Only
03593-06600
D
17. No.03993-52303
WARNING
03993-52303
Failure to properly set the Attachment
Interference Switch can result in
equipment damage, bodily harm, or death.
23. Noise Outside the Cab / for EU
This value indicates the noise level outside the machine
and refers to the noise perceived by the persons who are in
the vicinity of the work area.
< TB153FR >
No.03393-41031
< TB180FR >
No.05693-49035
for USA
for USA
