Takeuchi TB153FR User Manual

39
CONTROLS
Doors and Covers
Front Window (Cab)
WARNING
¡¡
¡¡
¡ Grasp the handles firmly with both
hands when opening and closing the
front window. Your head or hands may
get caught if they slip.
¡¡
¡¡
¡ When the front window is opened or
closed, it will come close to the head.
Be careful that the window dose not
strike the head.
¡¡
¡¡
¡ If you open the front window, be sure to
lock it in place with the knobs (latch) (2)
on the left and right sides. The window
may fall if it is not locked in place.
Opening
1. Grasp the left and right handles (1) and
press the knobs (2) with your thumb to
release the lock.
2. Pull the front window toward you and lift
while doing so.
3. Lift the front window fully and then release
your thumb from the knobs (2) and lock
the front window.
Closing
WARNING
When closing the front window, lower the
window slowly so as not to hit your head.
Lowering the window abruptly may result
in injury or damage the front window.
1. Grasp the left and right handles (1) and
press the knobs (2) with your thumb to
release the lock.
2. Pull down the front window and while
doing so, slide it to the front and slowly
lower it.
3. Lower the front window fully and then
release your thumb from the knobs (2) and
lock the front window.

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
