Takeuchi TB153FR User Manual

179
SPECIFICATIONS
Machine Dimensions
Units: mm (inches)
{ } : Canopy
TB153FR TB180FR
Standard Arm Long Arm Standard Arm Long Arm
Rubber Crawlers
A 5330 (209.8) 5350 (210.6) 6150 (242) 6175 (243.1)
B 1860 (73.2) ← 2140 (84.3) ←
C
2570 (101.3) {2585 (101.7)} ← 2765 (108.9) ←
D1110 (43.7) ← 1255 (49.4) ←
E 615 (24.2) ← 720 (28.3) ←
F 1985 (78.1) ← 2210 (87) ←
G 2500 (98.5) ← 2855 (112.4) ←
H 2000 (78.7) ← 2300 (90.6) ←
J 400 (15.7) ← 450 (17.7) ←
K 300 (11.8) ← 345 (13.5) ←
L 1285 (50.6) ← 1395 (55) ←
M 720 (28.3) ← 800 (31.4) ←
N 825 (32.4) ← 945 (37.2) ←
P 2000 (78.7) ← 2300 (90.6) ←
Q 4085 (160.8) 4105 (161.6) 4745 (186.8) 4775 (187.9)
R 1510 (59.4) ← 1855 (73.1) ←
S 430 (16.8) ← 500 (19.7) ←
T30° ←
U15° ←

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
