Takeuchi TB153FR User Manual

181
SPECIFICATIONS
Operating Range
Units: mm (inches)
Item
Standard Arm Long Arm
Rubber Crawlers
A Max. digging radius 5905 (232.4) 6195 (243.9)
B Max. ground digging radius 5765 (227.0) 6065 (238.7)
C Max. digging depth 3590 (141.3) 3900 (153.5)
D Max. vertical digging depth 2735 (107.7) 3030 (119.2)
E Max. digging height 5320 (209.4) 5490 (216.2)
F Max. dumping height 3710 (146.1) 3885 (152.9)
G Min. dumping height 1435 (56.5) 1125 (44.3)
H Max. vertical digging radius 3885 (153.0) 4075 (160.4)
J Max. raising height 320 (12.6) ←
K Max. lowering depth 325 (12.8) ←
TB153FR
Units: mm (inches)
Item
Standard Arm Long Arm
Rubber Crawlers
A Max. digging radius 6870 (270.5) 7195 (283.2)
B Max. ground digging radius 6715 (264.3) 7045 (277.4)
C Max. digging depth 4195 (165.2) 4545 (179.0)
D Max. vertical digging depth 3165 (124.6) 3495 (137.6)
E Max. digging height 6280 (247.2) 6460 (254.4)
F Max. dumping height 4295 (169.1) 4475 (176.3)
G Min. dumping height 1755 (69) 1405 (55.2)
H Max. vertical digging radius 4700 (185.1) 4795 (188.8)
J Max. raising height 505 (19.9) ←
K Max. lowering depth 410 (16.1) ←
TB180FR

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
