Takeuchi TB153FR User Manual

60
CONTROLS
Accessories
Radio
Operating precautions
¡To ensure safe operation of the machine, always be sure to keep the volume of the radio
down to a level where you can easily hear sounds from outside the machine.
¡Do not keep the radio playing for long periods of time with the engine stopped. Doing so
will drain the battery of its charge and make it difficult or impossible to restart the engine.
¡Be careful not to allow water or other liquids to come into contact with the radio . Doing so
may result in it being rendered inoperable.
¡Be careful not to insert cassette tapes backward. Doing so may damage the cassette
player. Insert tapes with the head of the tape facing to the right.
¡Always remove the cassette from the player when not in use.
Names of components
(1) (2) Power switch / volume control knob
Turn this knob clockwise. The “click” sound
indicates that the power supply is turned on.
Further turning increases the speaker
volume. If a tape is loaded in the radio, eject
the tape to switch to the radio.
(3) Tone control
¡Bass control knob
¡Treble control knob
VOL
PS/AS
BASS
LOUD DISP
M
H
BAND
SEEK
DN
SEEK
UP
MTL LOUD ST
FM1
FM2
AM
1
4
2
5
METAL
3
6
DC12V/24V
AUTO REVERSE CASSETTE STEREO RECEIVER
KRH–M867
TRE
16 153 6 7 8
1
2
12 10
11
9 5 4 13 14
L2C001

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
