Takeuchi TB153FR User Manual

90
OPERATION
Operating Procedures
Pay Attention to the Dozer Blade when
Digging
When digging deeply with the dozer blade
positioned at the front, be careful that the
boom cylinder and bucket do not hit the dozer
blade.
Operate with the dozer blade at the rear
whenever possible.
Caution on Digging Down with the Dozer
Blade
This dozer blade is designed for simple earth
pushing. Do not dig down deeply with the
dozer blade. Doing so could damage the
dozer blade and lower body.
E4D0431
E4D044

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
