SERVICE DATA
SPECIFICATION TABLES
5
2
SPECIFICATION TABLES 2B0AX003
Lower machinery
Power transmission device
Travel motor
Type
Variable displacement (2-speed) piston motor,
with counterbalance valve
Quantity 2
Reduction gears Type Epicyclic gearing (2-stage)
Travel brake Type Counterbalance valve, differential delay type
Parking brake Type Wet friction plate type
Undercarriage
Track
shoe
215000003
to 215002407
Type Rubber crawler
Number of core metal
(on one side)
Quantity 68
Shoe width mm (in.) 230 (9.06)
Lug height mm (in.) 25 (0.91)
Type Steel crawler, double grouser
Number of shoes
(on one side)
Quantity 35
Shoe width mm (in.) 230 (9.06)
Grouser height mm (in.) 15 (0.65)
from
215002408
Type Rubber crawler
Number of core metal
(on one side)
Quantity 70
Shoe width mm (in.) 230 (9.06)
Lug height mm (in.) 25 (0.91)
Type Steel crawler, double grouser
Number of shoes
(on one side)
Quantity 36
Shoe width mm (in.) -
Grouser height mm (in.) 15 (0.65)
Roller
Carrier roller
(on one side)
Quantity 2 (slide plate)
Track roller
(on one side)
Quantity 3
Track adjuster Type Grease cylinder type (with cushion spring)
Track gauge extension mechanism Hydraulic system
