SERVICE DATA
SPECIFICATION TABLES
6
2
SPECIFICATION TABLES 2B0AX003
Working equipment
Working dimensions (Standard arm)
Main structure
Backhoe attachment
Bucket capacity
Heaped capacity m
3
(ft
3
) 0.038 (1.34)
Struck capacity m
3
(ft
3
) 0.028 (0.99)
Bucket width
Standard mm (in.) 405 (16.0)
With side cutter mm (in.) 435 (17.1)
Bucket mass kg (lb) 34 (75)
Boom length mm (in.) 1705 (67.1)
Arm length Standard mm (in.) 930 (36.6)
Bucket wrist radius mm (in.) 520 (20.5)
Bucket wrist angle deg. 190
Boom swing angle
Left deg. 70
Right deg. 50
Eccentricity of boom swing pivot mm (in.) 50 (2.0)
Maximum reach mm (in.) 3815 (150.2)
Maximum reach at ground reference plane mm (in.) 3760 (148)
Minimum radius of ground level finishing mm (in.) 1325 (52.2)
Maximum digging depth
Rubber crawler mm (in.) 2190 (86.2)
Steel crawler mm (in.) 2200 (86.6)
Reach at maximum digging depth mm (in.) 1840 (72.4)
Maximum vertical digging depth
Rubber crawler mm (in.) 1780 (70.1)
Steel crawler mm (in.) 1790 (70.5)
Maximum height of cutting edge
Rubber crawler mm (in.) 3430 (135)
Steel crawler mm (in.) 3420 (134.6)
Reach at maximum height mm (in.) 1845 (72.6)
Maximum dumping height
Rubber crawler mm (in.) 2400 (94.5)
Steel crawler mm (in.) 2390 (94.1)
Reach at maximum dumping height mm (in.) 1725 (67.9)
Minimum dumping height
Rubber crawler mm (in.) 835 (32.9)
Steel crawler mm (in.) 825 (32.5)
Minimum radius of equipment and attachment mm (in.) 1450 (57.1)
Minimum radius of equipment at maximum front offset mm (in.) 1185 (46.7)
Overall height at minimum radius of equipment and attachment mm (in.) 2515 (99)
Overall height of equipment at maximum front offset mm (in.) 2515 (99)
Max. bucket offset distance
Left mm (in.) 395 (15.6)
Right mm (in.) 555 (21.9)
Boom
Integrated hydraulic cylinder,
drive swing type
Arm -
Bucket
Type -
Number of teeth Quantity 3
