Takeuchi TB215R Workshop Manual

SERVICE DATA
SPECIFICATION TABLES
7
2
SPECIFICATION TABLES 2B0AX003
Hydraulic cylinder
Digging force
Boom cylinder
Number of cylinders Quantity 1
Bore mm (in.) 60 (2.4)
Stroke mm (in.) 480 (18.9)
Arm cylinder
Number of cylinders Quantity 1
Bore mm (in.) 60 (2.4)
Stroke mm (in.) 385 (15.2)
Bucket cylinder
Number of cylinders Quantity 1
Bore mm (in.) 50 (2)
Stroke mm (in.) 355 (14)
Swing cylinder
Number of cylinders Quantity 1
Bore mm (in.) 60 (2.4)
Stroke mm (in.) 340 (13.4)
Maximum digging force
Bucket cylinder kN (lbf) 14 (3150)
Arm cylinder kN (lbf) 9.5 (2140)
Maximum lifting force Boom cylinder kN (lbf) 7.7 (1730)
Attachment (optional) -

Takeuchi TB215R Specifications

General

Brand	Takeuchi
Model	TB215R
Category	Excavators
Language	English
