Takeuchi TB215R Workshop Manual

SERVICE DATA
SPECIFICATION TABLES
8
2
SPECIFICATION TABLES 2B0AX003
Dozer blade
Type Straight type
Operation type Hydraulic hoisting type
Dozer blade cylinder
Number of cylinders Quantity 1
Bore mm (in.) 60 (2.4)
Stroke mm (in.) 120 (4.7)
Dimensions
Dozer blade dimensions
Width mm (in.) 1300 (51.2)
Height
mm (in.)
Standard
blade
Rubber
crawler
250 (9.8)
Steel
crawler
205 (8.1)
mm (in.) Long blade
Rubber
crawler
310 (12.2)
Steel
crawler
300 (11.8)
Cutting angle deg. 55
Distance between the front end of the dozer blade and the axis
of rotation
mm (in.) Standard blade 855 (33.6)
mm (in.) Long blade 1200 (47.2)
Dozer blade maximum lifting
mm (in.)
Standard
blade
Rubber
crawler
215 (8.5)
Steel
crawler
205 (8.1)
mm (in.) Long blade
Rubber
crawler
360 (14.2)
Steel
crawler
350 (13.8)
Dozer blade maximum lowering
mm (in.)
Standard
blade
Rubber
crawler
210 (8.3)
Steel
crawler
220 (8.7)
mm (in.) Long blade
Rubber
crawler
365 (14.4)
Steel
crawler
375 (14.8)
Dozer blade approach angle deg.
Standard
blade
Rubber
crawler
31
Steel
crawler
29
Long blade
Rubber
crawler
30
Steel
crawler
29

Takeuchi TB215R Specifications

General

Brand	Takeuchi
Model	TB215R
Category	Excavators
Language	English
