SERVICE DATA
TABLE OF MASSES
1
2
TABLE OF MASSES 2B1AX00
TABLE OF MASSES
Upper structure
kg (lb.)
Part name Remarks Mass
Engine Dry mass 103 (227)
Radiator With assembly parts attached 13 (28)
Main pump 13 (29)
Gear pump –
Hydraulic tank With assembly parts attached 20 (43)
Fuel tank With assembly parts attached 3 (6)
Control valve
(2nd, 3rd auxiliary line piping specifications)
With adapter attached 38 (84)
Pilot valve 2 (4)
Slew motor 22 (49)
Cab –
Canopy With roof attached 48 (105)
Counterweight 100 (220)
Counterweight (with added weight) –
Boom bracket 30 (65)
Swing cylinder 17 (37)
Lower structure
kg (lb.)
Part name Remarks Mass
Swivel joint 12 (27)
Slew bearing 18 (40)
Rubber crawler One side 55 (120)
Steel crawler One side –
Segmented rubber crawler –
Travel motor 18 (40)
Carrier roller –
Track roller 3 (7)
Front idler 14 (31)
Track adjuster 6 (12)
Dozer blade 50 (111)
Dozer blade cylinder 11 (23)
Spanner cylinder 6.4 (14.1)
Hoe attachment
kg (lb.)
Part name Remarks Mass
Boom 57 (125)
Arm 31 (68)
Arm (middle model) –
Arm (long model) –
Bucket (450-mm-wide model) With teeth 34 (76)
Boom cylinder 20 (44)
Arm cylinder 17 (37)
Bucket cylinder 9 (20)
