Special Feature
If you not get the required control codes for Barcode of ASCII code table columns 0 and 1
out of your computer you can use in addition to these Barcode control codes a set of
MTPL sequences to generate these control codes by printable ASCII characters. By this
measure the Barcode programs will remain fully compatible in spite of the additional
MTPL sequences.
Following control codes in Barcode strings can be substituted by the appropriate ANSI se-
quences:
Control Code
ANSI Sequence
(CSI = Hex 9B
or
Hex 1B 5B
or
ESC[ )
Example (Hex)
SUB CSI 26 Space s 1B 5B 32 36 20 73
EM CSI 25 Space s 1B 5B 32 35 20 73
DC4 CSI 20 Space s 1B 5B 32 30 20 73
DLE CSI 16 Space s 1B 5B 31 36 20 73
SI CSI 15 Space s 1B 5B 31 35 20 73
ANSI sequences with not matching parameters will be ignored.
These feature is not available with all printers with MTPL emulation.
Special firmware is possibly necessary. Please ask your dealer or representative!
