Taylor-Dunn MX-026-00 - Page 181

Illustrated parts
Parts
Page 33
* Not available at time of printing
Steering Linkage, Geared, SS-536, SS-546. MX-600
Item No. Part No. Description Qty
1 19-011-25 Cover 1
2 19-011-20 Steering Wheel 1
3 80-400-10 3/4”ID Bearing 2
4 88-060-22 1/4" X 3-1/2" NC Hex Bolt 2
5 88-068-82 1/4" Lockwasher 6
6 18-309-13 Plate and Sleeve, Weldment 1
7 20-031-20 Steering Shaft and Gear 1
8 31-255-10 Stem and Gear, Weldment 1
9 32-207-00 3/8" ID X 5/8" OD Bronze Bushing 1
10 45-003-10 Mounting Plate Gasket 1
11 31-254-00 36 Tooth, Spear Gear 1
12 88-069-81 1/4" Locknut 4
13 18-309-11 Bottom Plate 1
14 45-004-10 Gear Box Gasket 1
15 18-309-12 Gear Box Case 1
16 87-071-00 3/16" Zerk Fitting 1
17 71-505-05 Head Light mounting Bracket 1
18 88-060-25 1/4” X 4-1/2”NC HEX Bolt 4
19 32-203-00 3/4”ID X 7/8”OD Bronze Bushing 1
20 88-199-82 5/8" NF Jam Nut 1
