Maintenance, Service, and Repair
Transmission Page 11
8. Remove the final drive gear from the differential
housing.
9. Punch or drill a small hole into the center of both of
the intermediate shaft bore plugs.
10. Thread a sheet metal screw into each plug until the
bore plug is forced out.
11. Remove both snap rings from the intermediate shaft
bore.
12. Using a soft metal or hard wood dowel, drive the
intermediate shaft through the bearing just enough
to allow clearance for an ID bearing puller. Do not
attempt to drive the shaft out of the opposite end of
the transmission.
