Maintenance, Service, and Repair
Transmission Page 12
13. Remove the intermediate bearing with an ID bearing
puller.
14. While supporting the shaft and gear assembly,
repeat steps #12 and #13 for the opposite side
bearing and remove the intermediate shaft from
the housing.
15. Remove the o-rings from each end of the
intermediate shaft.
16. Remove the circlip from the input shaft.
17. Remove the input shaft from the housing.
18. Press the bearings off of the input shaft.
The shaft and gear assembly must be supported by hand during the
next step. Failure to properly support the shaft and gear assembly
could result in damage to the gear teeth.
