9. AVAILABLE DATA FROM KEYPAD
9.1. PARAMETERS
(Note: n = off-line, r = reserved to the customer, t = TDE-reserved)
SECT. DESCRIPTION FIELD DEFAULT Notes
P 1 JOG 1 speed ±100.0% 0.0%
P 2 JOG 2 speed ±100.0% 0.0%
P 3 JOG 3 speed ±100.0% 0.0%
P 4 Analogue speed reference offset
1/100000 parts on speed reference
±19999 0
P 5 Max CW speed limit
0÷105.0%
100.0%
P 6 Max CCW speed limit
0÷105.0%
100.0%
P 7 Position for curve 1 (encoder pulses) ±19999 (*) 0
P 8 Position for curve 2 (encoder pulses) ±19999 (*) 0
P 9 Offset (encoder pulses) with respect to resolver
zero
±19999 0
P 10 Gain for positioning (kv)
1÷100%
4
P 11 CW acceleration time
50÷19999 ms
400 ms n
P 12 CW deceleration time
50÷19999 ms
400 ms n
P 13 CCW acceleration time
50÷19999 ms
400 ms n
P 14 CCW deceleration time
50÷19999 ms
400 ms n
P 20 level |speed|+|REF| for constant modulation
0÷200.0 %
0.0%
P 21 Speed loop proportional gain for
|speed|+|REF|=0
0.5÷100.0
4.0
P 22 Speed loop lead time when |speed|+|REF|=0
Integral time P21
4.0÷150.0 ms
40.0 ms
P 23 Speed loop proportional gain
|speed|+|REF|>P20
0.5-100.0 4.0
P 24 Speed loop lead constant time when (integral
time x gain) for |speed|+|REF|>P20
4.0-150.0 ms 40.0 ms
P 25 Speed loop filter constant time
0.2÷20 ms
0.2 ms
P 27 Starting value of speed regulator integral ±100.0% 0.0% n
P 31 Torque signal offset (Itorq) ±100.0% 0.0%
P 32 Torque correction signal constant ±400.0% 100.0%
P 33 Current limit signal offset (Imax) ±100.0% 0.0%
P 34 Limit signal correction coefficient ±400.0% 100.0%
P 35 Max CW current limit
0÷100.0%
100.0%
P 36 Max CCW current limit
0÷100.0%
100.0%
P 41 Minimum speed level
0÷100.0%
0.25%
P 42 Maximum allowed speed level
0÷120.0%
110.0%
P 43 Lower level speed range for speed relay ±100.0% -100.0% n
P 44 Upper value speed range for speed relay ±100.0% 100.0% n
P 45 Lower value current range for speed relay ±100.0% -100.0% n
P 46 Upper value current range for speed relay ±100.0% 100.0% n
P 50 Reserved parameter access key
0÷9999
n
P 51 Drive identification number for the serial line
1÷255
255 r
P 52 Setting maximum motor speed (rpm/1')
375÷19000
2500 r
P 53 Number of motor poles
2÷12
6r
P 54 Number of resolver poles
2÷12
2r
P 55 Resolver phase ( degrees ) ±180.0 0 r
P 56 Motor rated current in % of drive rated current
10.0%÷100.0%
90.0% r
P 57 Motor thermal constant time TH
1.0÷600.0 sec.
30.0 sec. r
(*) from serial line “
±
32750”
