User manual 15-3

DSC/DSCT Series

15. DIMENSIONS AND SIZES

15.1. DIMENSIONS AND SIZES OF DSC DRIVES

330mm

290mmx

310mm

DSC-03N DSC-06N DSC-10N DSC-15N DSC-20N DSC-30N DSC-40N DSC-60N

DIMENSIONS mm.

x = 68 x = 100 x = 130 x = 192

WEIGHT Kg 5,2 7 8,7 9,5
