TDE MACNO DSC-03N - Power Circuit Ratings

User Manual 2-3
DSC/DSCT series
2.1.3. POWER CIRCUIT RATINGS
DSCT-03N DSCT-07N DSCT-15N DSCT-22N DSCT-28N DSCT-37N DSCT-47N
3-PHASE MAIN SUPPLY
3 x (340 ÷ 460 ) Veff. 45÷65 Hz
MAX OUT.3-PHASE
VOLTAGE
3 x Vi x 0.9 (Vi = voltage input)
OUTPUT FREQUENCY
0 ÷ 400 Hz
NOMINAL RMS CURRENT
(A )
3.5 7 15 22 28 37 47
MAX RMS CURRENT
( A )
100 ms per f=0
2.5 s per f>2.5 Hz
7 143044567494
CLAMPING VOLTAGE
720 V c.c.
OVERVOLTAGE LEVEL
(V)
800 Vcc
PEAK CLAMP CURRENT
A (t<0.3 sec.)
91824 36
MINIMUM VALUE OF
RESISTIVE LOAD
ȍ
(W)
82 (100W) 82 (100W)||
82 (100W)
≅
40
Ω
200W
15 (300W) +
15 (300W)
≅
30
Ω
600W
10 (300W) +
10 (300W)
≅
20
Ω
600W
