17
8303460000 Rev A IA672-04-01-Rev. I
D. To apply the new address, momentarily press the “FOLD” button.
See the display shows for a few seconds:
LAn Hold
This shows the LAN connection is on hold while acquiring the new address.
If you do not press “FOLD” soon enough, the display returns to normal and the old
address is kept.
If another device already has the address you are trying to set (duplicate
addresses), then after “Lan Hold” clears, the front panel will blink and the address
will return to what it was before the change was made.
Note
When you change the IP address from the front panel,
the Genesys™ LAN will switch to STATIC addressing.
( DHCP and Auto-IP addressing will be disabled)
5.3. LAN Reset
If it is necessary to reset the supply to the factory default LAN settings, use the front panel
to:
A. Press and hold the OVP/UVL button for 2 seconds.
B. The 7-segment displays will show:
LAn rES
C. Release the OVP/UVL button
D. Briefly pressed and release the OVP/UVL button again.
E. The displays will briefly show:
rES 0000
and the LAN will be reset to the default settings (listed below).
If the OVP/UVL button is not pressed again, the LAN settings will not be reset.
F. It may be required to AC cycle the power supply off and on. This ensures a new
network connection is established with the reset values.
In addition the DIAG:COMM:LAN:RES command may be sent to reset the LAN.
See section 11.6.6.
This display may not show if faults, such as
Enable or Shut-Off, are in progress
