2. SPECIFICATIONS
2.1. Power Supply Specifications
When using the LAN, the power supply ratings and accuracies are the same as for the
digital remote programming using RS-232 or RS-485. See the Technical Manual for
Genesys™ Power Supply for those specifications
2.2. LAN Specifications
ELECTRICAL
Ethernet
Meets IEEE 802.3u specifications
Auto-MDIX
Accepts patch or cross-over cable connection
Auto-Negotiate
Selects fastest of 10Base-T or 100Base-T networks
(10 or 100 Megabits per second)
NETWORK CONFIGURATION
MAC Address
TDK-Lambda assigned: 00:19:f9:xx:xx:xx
IP Address
View or set from front panel or embedded web page
DHCP
Get address from network server. Lease time service
Auto-IP
Create own IP address: 169.254.xx.xx
Static IP
Any IP fixed by operator
DHCP Lease Time
20 second minimum
DHCP Auto-Reconnect
Recover connection if DHCP server stops and restarts
Address Resolution
ARP protocol
Hostname
DNS and mDNS protocols. Operator settable hostname
Service Name
DNS-SD Service Discovery protocol
Duplicate IP Detection
Reject duplicate setting or disconnect from network
Subnet Mask
Mask set by DHCP or static
Default Gateway
Address set by DHCP or static
DNS Server
Address set by DHCP
VXI-11 Discovery
Find connected instruments
SNMP Ping Server
Verify LAN connection to instrument
LAN Reset
Reset configuration from front panel or SCPI command
LAN PROTOCOLS
IPv4
Internet Protocol version 4
Instrument Protocols:
VXI-11
Supports Core channel, not Abort or Interrupt channels
VISA
VXI-11 compliant, uses RPC and Portmapper, SCPI cmds
TCP Sockets
Send SCPI commands to port 8003
UDP Sockets
Send SCPI commands to port 8005
HTTP
Web page server with Java scripts
COMMANDS
SCPI
SCPI 1999 compliant command, measure and status
IEEE-488.2
Condition and event register tree
Serial Pass-Through
Send native RS-232 commands with abilities beyond SCPI
