13. SYSTEM:ERROR? MESSAGES
These are the system error messages which may be returned from the “SYST:ERR?” query.
See section 11.8.1 for a description of this system error queue
ERROR
ERROR MESSAGE
ERROR DESCRIPTION
0
“No error”
No error reported
-100
“Command error”
LAN card receives command with unspecified error
-101
“Invalid Character”
A character was received that is not:
a-z, A-Z, 0-9, ?, *, :, ;,period, space, CR, LF
-102
“Syntax error”
LAN card receives unrecognized command word
-104
“Data type error”
LAN card receives command parameter with wrong type of data.
Example: a letter where a number is expected.
-109
“Missing parameter”
Valid command received but not enough parameters.
-112
“Program word too long”
Command word had more than 14 characters before separator
(space or colon) was found
-131
“Invalid Suffix”
Attempt to select multi-drop address > 30
-222
“Data out of range”
Attempt to program voltage, current or OVP beyond supply limits
-241
“Hardware Missing”
When operating in RS-485 Multi-drop mode, an attempt was made
to address a non-existent supply.
-350
“Queue Overflow”
Too many SYST:ERR messages are stored in this queue and the
newest messages are discarded. The max. number of stored
messages is 10.
+300
“Execution error”
General execution error.
+301
“PV above OVP”
Attempt to program voltage above OVP setting.
(or more exactly, PV not "5% of voltage rating" below OVP)
+302
“PV below UVL”
Attempt to program voltage below UVL setting.
(or more exactly, PV not "5% of voltage rating" above UVL)
+304
“OVP below PV”
Attempt to set OVP below voltage setting.
(or more exactly, OVP not "5% of voltage rating" above PV)
+306
“UVL above PV”
Attempt to set UVL above voltage setting.
(or more exactly, UVL not "5% of voltage rating" below PV)
+307
“On during fault”
Attempt to set supply output “ON” when a fault exists
+320
“Fault shutdown”
General message for non-specified shutdown
+321
“AC fault shutdown”
Brown-out or phase-loss shutdown occurred
+322
“Over-Temperature”
Over-temperature shutdown occurred
+323
“Fold-Back shutdown”
Fold-Back shutdown occurred
+324
“Over-Voltage shutdown”
Over-Voltage shutdown occurred
+325
“Analog shut-off shutdown”
Shut-Off occurred from rear panel J1
+326
“Output-Off shutdown”
Output-Off occurred from front panel button
+327
“Enable Open shutdown”
Enable Open occurred from rear panel J1
