TECDrive20-EU Series Inverter Function parameters
-78-
Function
code
Name
Description
Default
Modify
Output frequency
FDT level
Y1,
RO1, RO2
FDT lag
Setting range of P08.32: 0.00Hz–P00.03
(the max. frequency)
Setting range of P08.33 and P08.35:
0.0–100.0%
Setting range of P08.34: 0.00Hz–P00.03
(the max. frequency)
P08.36
Amplitude
value for
frequency
arrival
detection
When the output frequency is among the below
or above range of the set frequency, the
multi-function digital output terminal will output
the signal of "frequency arrival", see the diagram
below for detailed information:
Y1,
RO1, RO2
Output frequency
t
Setting
frequency
P08.36
t
P08.36
Setting range: 0.00Hz–P00.03 (the max.
frequency)
0.00Hz
○
P08.37
Energy
consumption
brake enable
This parameter is used to control the internal
braking unit.
0: Disabled
1: Enabled
Note: It is only applicable to inverter models that
are built in braking units.
0
○
