TECDrive20-EU Series Inverter Function parameters
-79-
Function
code
Name
Description
Default
Modify
P08.38
Energy
consumption
brake
threshold
voltage
After setting the original bus voltage to brake the
energy, adjust the voltage appropriately to brake
the load. The factory changes with the voltage
level.
Setting range: 200.0–2000.0V
In order to prevent customers set the value is too
large, it is recommended setting range:
Voltage
220V/230V
400V
460V
Range
375–400V
685–750V
715–780V
For
220/230
V
inverters:
380.0V
○
For 400V
inverters:
700.0V
For 460V
inverters:
740.0V
P08.39
Cooling fan
running mode
0: Common running mode
1: Keeps running after being powered on
2: Runs when the inverter ramp frequency is no
less than 0 Hz and the inverter output current is
no less than 10% of the inverter rated current. If
the inverter ramp frequency is 0 Hz and the
inverter output current is less than 10% of the
inverter rated current or the inverter stops
running, the fan stops running within 1 minute.
0
○
P08.40
PWM selection
0x0000–0x0021
Ones place: PWM mode selection
0: PWM mode 1, three-phase modulation and
two-phase modulation
1: PWM mode 2, three-phase modulation
Tens place: low-speed carrier frequency limit
mode
0: Low-speed carrier frequency limit mode 1, the
carrier frequency will limit to 1k or 2k if it exceeds
2k at low speed
1: Low-speed carrier frequency limit mode 2, the
carrier frequency will limit to 4k if it exceeds 4k at
low speed
2: No limit
0x0001
◎
P08.41
Overmodulation
selection
Ones place:
0: Disabled
1: Enabled
0x00
◎
