Speed: different speeds are available. By “Autonegotiation all
Capable” autonegotiation is done. By the other settings, the speed
is set, but master/slave is still autonegotiated.
Detected Speed: Here the detected speed is displayed, which is autonegotiated
between MediaGateway and connected device on this port.
Drop ingress packets with…:
Source IP: one IP address can be configured here. It is a filter for incoming traffic. Data
with configured IP address as source IP address will be dropped and not forwarded,
when incoming on this port.
Destination IP: one IP address can be configured here. It is a filter for incoming traffic.
Data with configured IP address as destination IP address will be dropped and not
forwarded.
Drop mirrored packets with…:
Each field allows one MAC address. In total
six MAC addresses can be configured. It is a
filter for outgoing traffic. Data with
configured MAC address as destination MAC
address will be dropped and forwarded
Note: This drop feature is only available if mirroring on this port is activated
