Test Mode: For 100BASE-T1 Ports it is possible to set a BroadR-Reach Physical Layer
Test Mode. There are five test modes defined in the BroadR-Reach specification to
check the compliance of a port.
Warning: When a test mode has been selected there is no communication possible for
this port.
Important: In the case of BroadR-Reach master, it is mandatory to restart the switch to
recover link.
Note: For compliance testing an oscilloscope with special test software is necessary.
Drop ingress packets with…:
Source IP: one IP address can be configured here. It is a filter for incoming traffic. Data
with configured IP address as source IP address will be dropped and not forwarded,
when incoming on this port.
Destination IP: one IP address can be configured here. It is a filter for incoming traffic.
Data with configured IP address as destination IP address will be dropped and not
forwarded.
Redirect packets to…: By defining an Ethernet port (or the SFP-slot) you can redirect
packets with a specific destination IP address to this port, independent from any other
configuration. It means, that the packet is not sent to the port it was originally
supposed to be sent. This function is only available for IP layer.
3.6.2 Port Information while Single VLAN tagging is active
If IEEE 802.1q (VLAN) mode is hooked (see CHAPTER 3.5.1) but not double tagging,
port based single VLAN is activated.
In this mode, the routing through the MediaGateway is defined by the configuration of
each port.
Grey fields are not configurable and have standard values or no values.
