Technica Engineering MEDIAGATEWAY User Manual

MEDIAGATEWAY User Manual
85
This method returns a SOME/IP message with return code 0x00 (OK) and the payload
contains the current status of both WakeUp Lines
2 Byte
1
2
Status Line 1
Status Line 2
Field Name
Data Type
Description
Status Line 1
UINT8
0x00 for WakeUp Line 1 is LOW
0x01 for WakeUp Line 1 is HIGH
Status Line 2
UINT8
0x00 for WakeUp Line 2 is LOW
0x01 for WakeUp Line 2 is HIGH
7.8 Set Port Enabled/Disabled (only 100BASE-T1-Ports)
Via this method the user can enable or disable 100BASE-T1 ports, similarly to the
Enable port function on the webserver for the 100BASE-T1 ports.
Request with:
Method ID: 0x0008
Length: 0xA
Payload: 2 bytes contain the information, which port is enabled/disabled
2 Byte
1
2
100BASE-T1 Port selection
Enable/disable
