Note: For compliance testing an oscilloscope with special test software is necessary.
Drop ingress packets with…:
Source IP: one IP address can be configured here. It is a filter for incoming traffic. Data
with configured IP address as source IP address will be dropped and not forwarded,
when incoming on this port.
Destination IP: one IP address can be configured here. It is a filter for incoming traffic.
Data with configured IP address as destination IP address will be dropped and not
forwarded.
Redirect packets to…: By defining an Ethernet port (or the SFP-slot) you can redirect
packets with a specific destination IP address to this port, independent from any other
configuration. It means that the packet is not sent to the port it was originally supposed
to be sent. This function is only available for IP layer.
3.6.3 Port Information while Double VLAN tagging is active
IEEE 802.1q (VLAN) mode is hooked (see CHAPTER 3.5.1) and double tagging is
hooked, too. In this mode, the routing through the MediaGateway is defined by the
configuration of each port.
Grey fields are not configurable and have standard values or no values.
Note: This is the recommended use case of the MediaGateway. Networks in vehicles
are often already single-tagged. In this use case you can prove the flexibility of the
MediaGateway, being independent from single-tagged networks.
