Page #86 background image
MEDIAGATEWAY User Manual
86
Field Name
Data Type
Description
100BASE-T1 Port selection
UINT8
0x00: S1-P0
0x01: S1-P1
0x02: S1-P2
0x03: S1-P3
0x04: S2-P0
0x05: S2-P1
0x06: S2-P2
0x07: S2-P3
0x08: S3-P0
0x09: S3-P1
0x0A: S3-P2
0x0B: S3-P3
Enable/disable
UINT8
0x00 for disable
0x01 for enable
Response:
This method returns a SOME/IP message with return code 0x00 (OK).
7.9 Set Port to Master/Slave (only 100BASE-T1-Ports)
Via this method the user can set 100BASE-T1 ports to master or slave,similarly to the
BroadR-Reach® mode function on the webserver for the 100BASE-T1 ports.
Request with:
Method ID: 0x0009
Length: 0xA
Payload: 2 bytes contain the information, which port is set to master/slave.
2 Byte
1
2
100BASE-T1 Port selection
BroadR-Reach® mode
