Technica Engineering MEDIAGATEWAY

MEDIAGATEWAY User Manual
72
The same other way around: S1-P8 and S2-P8 must forward the data from S1-
P2 to S3-P8 without touching the outerVLAN tag => set VLAN membership to
0x12 and set Egress VID remarking for outerVLAN tags to Normalized.
And
Do a save
Now you have access on the “Inject”-Port by any other device to the DUT_2 in
our example.
