Technica Engineering MEDIAGATEWAY User Manual

MEDIAGATEWAY User Manual
78
Description of the 21 ports and the assigned value for “nr_port”:
Port Number [nr_port]
Real Port
0
S1-P0 (100BASE-T1-port)
1
S1-P1 (100BASE-T1-port)
2
S1-P2 (100BASE-T1-port)
3
S1-P3 (100BASE-T1-port)
4
S2-P0 (100BASE-T1-port)
5
S2-P1 (100BASE-T1-port)
6
S2-P2 (100BASE-T1-port)
7
S2-P3 (100BASE-T1-port)
8
S3-P0 (100BASE-T1-port)
9
S3-P1 (100BASE-T1-port)
10
S3-P2 (100BASE-T1-port)
11
S3-P3 (100BASE-T1-port)
12
S1-P5 (RJ-45- port)
13
S2-P5 (RJ-45-port)
14
S3-P5 (SFP Cage-port)
15
S1-P4 (internal GB-port)
16
S1-P8 (internal GB-port)
17
S2-P8 (internal GB-port)
18
S2-P8 (internal GB-port)
19
S3-P8 (internal GB-port)
20
S3-P8 (RJ-45)
Table 6-1: assigned value for “Nr_ports”
Description of payload of the Board Configuration frame, starting with byte “0” at the
beginning of the payload of SOME/IP frame:
[bytes]
Values
0 to 1
HW Version
2 to 21
UUID
22 to 24
Firmware version
25 to 27
Enabled function (gateways)
28
MS Restart Status
(Nr_port x 21) + 29
Port Number
(Nr_port x 21) + 30
Port Name
(Nr_port x 21) + 31 to (Nr_port x 21) + 32
Defined Default VLAN ID
(Nr_port x 21) + 33
Inner VID Remarking
(Nr_port x 21) + 34
Outer VID Remarking
