Technica Engineering MEDIAGATEWAY User Manual

MEDIAGATEWAY User Manual
80
Description of payload of the Board Configuration frame, starting with byte “0” at the
beginning of the payload of SOME/IP frame:
[bytes]
Values
(Nr_port x 42) + 0
Port Number
(Nr_port x 42) + 1 to (Nr_port x 42) + 2
Time for Link Up
(Nr_port x 42) + 3
Link Status
(Nr_port x 42) + 4
Link Quality
(Nr_port x 42) + 5 to (Nr_port x 42) + 6
BitrateRx [Mbit/s]
(Nr_port x 42) + 7 (Nr_port x 42) + 8
BitrateTx [Mbit/s]
(Nr_port x 42) + 9 to (Nr_port x 42) + 12
RxErrorPkts
(Nr_port x 42) + 13 to (Nr_port x 42) + 16
RxGoodPkts
(Nr_port x 42) + 17 to (Nr_port x 42) + 20
TxErrorPkts
(Nr_port x 42) + 21 to (Nr_port x 42) + 24
TxGoodPkts
(Nr_port x 42) + 25 to (Nr_port x 42) + 28
RxDropPkts
(Nr_port x 42) + 29 to (Nr_port x 42) + 32
TxDropPkts
(Nr_port x 22) + 33 to (Nr_port x 22) + 36
TxFrameinDisc
(Nr_port x 22) + 37 to (Nr_port x 22) + 38
Nr_disconnections
(Nr_port x 22) + 39 to (Nr_port x 22) + 40
Last disconnection time in [ms]
(Nr_port x 42) + 41
Separator Byte
Table 6-3: Specific information of bytes
