13
1 Getting started
DMS3-CTC-25-282 v1.0
WPS LED
For more information about WPS, see “4.1 Connecting your wireless client via WPS” on page 36.
Ethernet LED
TV LED
Voice LED
Off No wireless clients connected or the status LEDs are deactivated.
Both the 2.4 GHz and 5 GHz access point have a dedicated Wireless LED.
Colour State Description
Green Solid On Client successfully registered via WPS.
Orange Blinking WPS registration ongoing.
Red Blinking Error occurred.
Colour State Description
Colour State Description
Green Solid on Network device connected to the Ethernet switch.
Blinking Network device connected to the Ethernet switch and sending/receiving
data or the status LEDs are deactivated.
Off No Ethernet connection on your local network or the status LEDs are
deactivated.
Colour State Description
Green Solid on Set-Top Box (STB) connected to the TG789vac v2.
Blinking Unknown STB connected to the TG789vac v2.
Off No STB connected to the TG789vac v2.
Colour State Description
Green Solid on Registered at your VoIP provider, no activity.
Blinking Registered at your VoIP provider, activity.
Off Not registered to your VoIP provider or the status LEDs are deactivated.
