TechniSat DIGITRADIO 585 User Manual

45
DE
EN
FR
IT
NL
DA
PL
SK
SL
1 MUTE 11 PRESET
2 VOLUME/ 12 Search for Track/Backwards
3 ALARM 13 Search for Track/Forwards
4 IR receiver 14 BACK
5 MODE 15 Play/Pause
6 SLEEP 16 Scroll&Select/Snooze
7 INFO 17 Stop
8 MENU 18 CD Eject
9 Display 19 Speaker
10 CD compartment
20 Telescopic antenna 23 AUX IN
21 DC IN 24 USB port
22 Headphone connection 25 Antenna connection
1.3 Remote control
1 On/Standby
2 Eject
3 Back
4 Play/Pause
5 Stop
6 Forward
7 Playback options
8 MENU
9 OK
10 Arrow keys
11 BACK
12 SCAN
13 MUTE
14 MODE
15 Volume
16 INFO
17 Alarm 1
18 Alarm 2
19 Snooze
20 Sleep timer
21 Number buons 1-12

TechniSat DIGITRADIO 585 Specifications

General

Package depth	255 mm
Package width	300 mm
Package height	245 mm
Package weight	4070 g
Bluetooth	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Display type	OLED
Display diagonal	2.42 \
RMS rated power	20 W
Audio formats supported	MP3
Power source	AC
AC input voltage	230 V
DC input voltage	12 V
AC input frequency	50 Hz
Power consumption (standby)	1.64 W
Power consumption (typical)	24 W
Radio type	Personal
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	24
Thermometer	-
Antenna type	External
Product color	White
Volume control	Rotary
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, SWE, TUR
Number of built-in speakers	2
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	215 mm
Width	240 mm
Height	150 mm
Weight	3160 g
