TechniSat DIGITRADIO 585 User Manual

57
DE
EN
FR
IT
NL
DA
PL
SK
SL
6.4.7 Visual displays
Current source
Station name,
track, artist,
additional info,
menu, lists
Time
Status bar
Depending on the selected function/source, the visual display shown may
vary. Take note of the instructions on the display.
7 Menu operation
Menu navigation primarily takes place using the MENU, /// and OK buons
on the remote control.
The menu is divided into the respective submenu for the currently selected source
and the main menu. To navigate in submenus, either press the OK buon or
alternatively the  buon.
* highlights the current selection.
You can go back one step by pressing the BACK or  buon.
Close menu: press BACK or MENU multiple times or wait for approx. 15
seconds.
7.1 Main menu
The main menu takes you to all the functions and seings for theDIGITRADIO 585.
> Press the MENU buon to access the main menu.
If you are currently in a playback source, you can use the MENU buon to
access the submenu for this source. To reach the main menu while in the
open submenu, use the  or > Main Menu buons to select the Main
menu item and press OK.
7.2 Source selection
> Press the MODE buon as oen as required until the desired source is shown
in the display.
Alternatively:
> Press the MENU buon.
If you are in a submenu, select the main menu as described in Section 7.1.

TechniSat DIGITRADIO 585 Specifications

General

Package depth	255 mm
Package width	300 mm
Package height	245 mm
Package weight	4070 g
Bluetooth	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Display type	OLED
Display diagonal	2.42 \
RMS rated power	20 W
Audio formats supported	MP3
Power source	AC
AC input voltage	230 V
DC input voltage	12 V
AC input frequency	50 Hz
Power consumption (standby)	1.64 W
Power consumption (typical)	24 W
Radio type	Personal
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	24
Thermometer	-
Antenna type	External
Product color	White
Volume control	Rotary
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, SWE, TUR
Number of built-in speakers	2
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	215 mm
Width	240 mm
Height	150 mm
Weight	3160 g
