TechniSat DIGITRADIO 585 User Manual

79
DE
EN
FR
IT
NL
DA
PL
SK
SL
19.3 Alexa control commands
Here is a list of possible Alexa voice control commands.
Alexa, play <Radio Station Name> in the kitchen (if the DIGITRADIO 585 has been
allocated to the room "Kitchen", only via TuneIn).
Alexa, play <Artist> on <Device Name> (only with Amazon Prime account).
Alexa lower the volume in the kitchen.
Alexa, increase the volume in the kitchen.
Alexa, set the volume in the kitchen to 5 (warning: the volume on the device can be
adjusted to 32 levels, but only 10 via Alexa).
Alexa, switch <Device Name> on/o.
Alexa, play the next/previous song/track on <Device Name> (in CD mode).
Alexa, Stop/Pause <Device Name> (in CD mode).
<Device Name> is the device name you allocated to the DIGITRADIO 585
in the UNDOK App (e.g. Kitchen, Living Room). Alexa must have found the
DIGITRADIO 585 under this device name so it can control it.
20 Cleaning
To prevent the risk of electric shock, you must not clean the device using a
wet cloth or under running water. Remove the mains plug prior to cleaning!
You must not use scouring pads, scouring powder and solvents such as
alcohol or petrol.
Do not use any of the following substances: salt water, insecticides, chlorine
or acid-based solvents (ammonium chloride), scouring powder.
Clean the housing using a so, damp cloth. Do not use solvents, spirit,
thinners, etc.; you could damage the surface of the device.
Only clean the display with a so, coon cloth. If required, use a coon cloth
with small amounts of non-alkaline, diluted, water or alcohol-based soap
solution.
Use the coon cloth to gently rub the surface until it is completely dry.

TechniSat DIGITRADIO 585 Specifications

General

Package depth	255 mm
Package width	300 mm
Package height	245 mm
Package weight	4070 g
Bluetooth	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Display type	OLED
Display diagonal	2.42 \
RMS rated power	20 W
Audio formats supported	MP3
Power source	AC
AC input voltage	230 V
DC input voltage	12 V
AC input frequency	50 Hz
Power consumption (standby)	1.64 W
Power consumption (typical)	24 W
Radio type	Personal
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	24
Thermometer	-
Antenna type	External
Product color	White
Volume control	Rotary
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, SWE, TUR
Number of built-in speakers	2
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	215 mm
Width	240 mm
Height	150 mm
Weight	3160 g
