TechniSat DIGITRADIO 585 User Manual

61
DE
EN
FR
IT
NL
DA
PL
SK
SL
11.2 DAB radio reception
> Press the MODE buon as oen as required until [DAB Radio] appears in the
display.
Alternatively:
> Press the MENU buon and then select [Main menu > DAB].
If you are in a submenu, select the main menu as described in Section 7.1.
If DAB is being started for the first time, a complete station scan is
performed. The station list is then shown (see Section 11.4).
11.3 Performing a station scan
The automatic scan scans all DAB+ band III channels and thereby finds all stations
being broadcast within the reception area.
Aer the scan is complete, the first station is played back in alphanumeric
order.
> In order to perform a complete scan, press the SCAN buon. "Scan" appears
in the display. The scan starts and the progress bar appears in the display.
> When completed, press  or  and OK to select a station.
> Alternatively: press the MENU buon and select using  or [Scan]. Confirm
by pressing OK.
If no stations are found, check the antenna and change the installation
location if required (section6.3.1).
11.3.1 Manual scan
Proceed as follows if you want to run a station scan manually:
> Select [Menu > Set Manually] and press the OK buon.
> Selecta station frequency and press the OK buon.
If stations are being broadcast on the selected frequency, this will be
indicated on the stability bar (see also Section 11.8). If these stations are not
currently included in your station list, they will now be stored there.
11.4 Selecting stations
> You can check the stations found on the device. To do so press  or .
> To select a station press OK.

TechniSat DIGITRADIO 585 Specifications

General

Package depth	255 mm
Package width	300 mm
Package height	245 mm
Package weight	4070 g
Bluetooth	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Display type	OLED
Display diagonal	2.42 \
RMS rated power	20 W
Audio formats supported	MP3
Power source	AC
AC input voltage	230 V
DC input voltage	12 V
AC input frequency	50 Hz
Power consumption (standby)	1.64 W
Power consumption (typical)	24 W
Radio type	Personal
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	24
Thermometer	-
Antenna type	External
Product color	White
Volume control	Rotary
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, SWE, TUR
Number of built-in speakers	2
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	215 mm
Width	240 mm
Height	150 mm
Weight	3160 g
