TechniSat DIGITRADIO 585 User Manual

72
now established. The signal bar in the status bar of the display indicates
whether the connection has been established.
To cancel the entry, select and press the OK buon. If you make a
typing error you can delete the last leer entered using .
17.2.1 WPS connection
> Select WPS set-up if your router has the WPS function. This establishes a
direct connection to the router without having to enter the WiFi password.
If you activate WPS on your router, please observe its instruction manual.
> Start WPS on your router by pressing the corresponding buon.
> On the DIGITRADIO 585, select [Press Buon]. Take note of the instructions
on the display.
> If your router supports the WPS PIN, select PIN on the DIGITRADIO 585 and
take note of the PIN shown in the display. This PIN must then be entered on
the router.
To find out more on the current connection select Seings.
Select Manual seing, if you know your network parameters and would like
to configure them manually. Take note of the instructions on the display.
Select Delete network profile, to delete connections no longer required.
Select Allow WiFi connection in standby mode if the WiFi connection
should be retained in standby mode as well. This seing increases power
consumption but enables App control via the TechniSat CONNECT App.
17.3 Time seings
> Press the MENU buon and then select [Main Menu > System Seings >
Time and Date].
If you are in a submenu, select the main menu as described in Section 7.1.
> Select [Time/date seing] to set the time and date manually.
Use the  or  buons to select a value. Change it using the  or 
buons.
> Confirm by pressing OK.

TechniSat DIGITRADIO 585 Specifications

General

Package depth	255 mm
Package width	300 mm
Package height	245 mm
Package weight	4070 g
Bluetooth	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Display type	OLED
Display diagonal	2.42 \
RMS rated power	20 W
Audio formats supported	MP3
Power source	AC
AC input voltage	230 V
DC input voltage	12 V
AC input frequency	50 Hz
Power consumption (standby)	1.64 W
Power consumption (typical)	24 W
Radio type	Personal
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	24
Thermometer	-
Antenna type	External
Product color	White
Volume control	Rotary
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, SWE, TUR
Number of built-in speakers	2
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	215 mm
Width	240 mm
Height	150 mm
Weight	3160 g
