TechniSat DIGITRADIO 585 User Manual

76
> You can now set the brightness in three steps from High to Medium to Low
and O (only in standby mode).
> Confirm the selection with OK.
> You return to the menu by pressing the MENU buon.
17.10 Data protection notice
> Press the MENU buon and then select [Main Menu > System Seings >
Data Protection].
If you are in a submenu, select the main menu as described in Section 7.1.
Here you will find a link to the current data protection information relating to your
device.
> You return to the menu by pressing the MENU buon.
18 Charging function for external devices
The DIGITRADIO 585 has a wired and wireless (to Qi standard) charging function for
external devices such as mobile phones and smartphones.
Warning: Do not use both variants at the same time. This can cause damage
to your devices.
18.1 Wired charging of external devices
Use the original charging cable (USB) for your external device and insert the USB
plug into the USB port (24) on the rear of the DIGITRADIO 585.
The external device can be charged at a maximum of 5 V and 1 A.
18.2 Wireless charging of external devices
If your external device has a wireless charging function (wireless charging to Qi
standard), you can place it on the charging mat on the top of the DIGITRADIO
585. The display of your external device must be facing upwards when doing so. If
correctly orientated, the charging process will begin automatically. Please refer to
the instruction manual for your external device for more information on wireless
baery charging.
19 Control via Amazon Alexa
You can control the DIGITRADIO 585 conveniently via an Amazon Echo device using
the Alexa voice assistant. Several basic requirements are needed for this.
1. The DIGITRADIO 585 must be connected to the Internet.
2. You need an Amazon Alexa compatible device, such as Amazon Echo,
which has a registered Amazon account and is also connected to the
Internet.
3. The DIGITRADIO 585 and Amazon Echo device must be located on the
same network.

TechniSat DIGITRADIO 585 Specifications

General

Package depth	255 mm
Package width	300 mm
Package height	245 mm
Package weight	4070 g
Bluetooth	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Display type	OLED
Display diagonal	2.42 \
RMS rated power	20 W
Audio formats supported	MP3
Power source	AC
AC input voltage	230 V
DC input voltage	12 V
AC input frequency	50 Hz
Power consumption (standby)	1.64 W
Power consumption (typical)	24 W
Radio type	Personal
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	24
Thermometer	-
Antenna type	External
Product color	White
Volume control	Rotary
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, SWE, TUR
Number of built-in speakers	2
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	215 mm
Width	240 mm
Height	150 mm
Weight	3160 g
