TechniSat DIGITRADIO 585 User Manual

63
DE
EN
FR
IT
NL
DA
PL
SK
SL
By pressing the INFO buon several times, dierent information can be
scrolled through, such as station type, multiplex name, frequency, signal error
rate, data bit rate, station format, date.
11.9 Dynamic Label Plus
If supported by the programme provider, the Dynamic Label Plus service also allows,
for example, the name of the current programme or the track and artist to be
displayed.
11.10 Seing DRC
The compression rate balances dynamic vibrations and thereby any volume
variations that occur.
> Press the MENU buon and select > [Volume Adjustment] to select the
desired compression rate.
> With the compression rate choose:
DRC high - High compression
DRC low - Low compression
DRC o - Compression switched o
> Confirm by pressing OK.
11.11 Deleting inactive stations
> Press the MENU buon and use  or  to select > [Delete inactive
stations].
> Confirm by pressing OK.
> Using  or , select > [Yes] and confirm by pressing OK.
11.12 Sorting the stations
> Press the MENU buon and then  or to select > [Station order].
> Select a sorting type with  or  and confirm your selection with OK.
You can choose between: Alphanumeric, Provider and Valid.
12 FM mode
12.1 Switching on the radio mode
> Press the MODE buon as oen as required until [FM Radio] is shown in the
display.
Alternatively:
> Press the MENU buon and select [Main Menu > FM]. If you are in a
submenu, select the main menu as described in Section 7.1.

TechniSat DIGITRADIO 585 Specifications

General

Package depth	255 mm
Package width	300 mm
Package height	245 mm
Package weight	4070 g
Bluetooth	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Display type	OLED
Display diagonal	2.42 \
RMS rated power	20 W
Audio formats supported	MP3
Power source	AC
AC input voltage	230 V
DC input voltage	12 V
AC input frequency	50 Hz
Power consumption (standby)	1.64 W
Power consumption (typical)	24 W
Radio type	Personal
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	24
Thermometer	-
Antenna type	External
Product color	White
Volume control	Rotary
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, SWE, TUR
Number of built-in speakers	2
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	215 mm
Width	240 mm
Height	150 mm
Weight	3160 g
