Section
7-2445A/2455A
Service
OPTIONS
INTRODUCTION
This
section contains a general description of instru-
ment options available at the time of publication of this
manual.
Additional information about instrument options
and
option availability
can
be
obtained either by consulting
the current Tektronix Product Catalog or
by
contacting
your local Tektronix
Field
Office or representative.
POWER CORD OPTIONS
Instruments
are
shipped with the detachable power-
cord configuration ordered by the customer. Descriptive
information about the international power -cord options is
provided
in
Section
2,
"Preparation for Use."
The
following
list identifies
the
Tektronix part numbers for the optional
power cords
and
associated fuses.
Option
A1
(Universal Euro)
Power cord
(2.5
m)
Fuse
(1.6
A,
250
V,
5 x
20
mm,
Quick-acting)
Option A2 (UK)
Power cord
(2.5
m)
Fuse
(1.6
A,
250
V,
5 x
20
mm,
Quick-acting)
Option A3 (Australian)
Power Cord
(2.5
m)
Fuse
(1.6
A,
250
V,
5 x
20
mm,
Quick-acting)
Option A4 (North American)
161-0104-06
159-0098-00
161-0104-07
159-0098-00
161-0104-05
159-0098-00
Power Cord
(2.5
m)
161-0104-08
Fuse
(2
A,
250
V,
AGC/3AG, Fast-blow) 159-0021-00
Option
AS
(Switzerland)
Power Cord
(2.5
m)
161-0167-00
Fuse
(1.6
A,
250
V,
5 x
20
mm,
Quick-acting) 159-0098-00
OPTION 1R
When
the oscilloscope is ordered with Option 1
R,
it
is
shipped
in
a configuration that permits easy installation
into a 19-inch-wide electronic-equipment rack.
An
optional rear-support kit is also available for
use
when rackmounting the instrument. Using this optional
rear-support kit enables the rackmounted instrument to
meet appropriate electrical
and
environmental
specifications.
Connector-mounting holes are provided
in
the front
panel
of the rackmounted instrument. These enable con-
venient accessing of the four bnc connectors
(CH
2
SIGNAL
OUT,
A
GATE
OUT,
B
GATE
OUT,
and
EXT
z
AXIS
IN)
and
the two
PROBE
POWER
connectors located
on
the rear
panel.
Additional cabling
and
connectors
required to implement any front-panel access to the rear-
panel
connectors
are
supplied by the user; however, these
items
can
be
separately ordered from Tektronix.
Complete rackmounting instructions
are
provided
in
a
separate document shipped with Option 1
R.
These instruc-
tions also contain appropriate procedures to convert a
standard instrument into the Option 1 R configuration by
using the rackmounting conversion kit.
OPTION
01
Option
01
(DMM) adds a 4-1/2 digit, fully autoranging
digital multimeter which measures
de
and
ac
voltage
and
current, resistance, dBV, dBm, continuity,
and
tempera-
ture. Option 1 B is the same
as
Option
01
except that the
temperature probe
is
not included. Measurement results
and
DMM
messages are displayed
on
the top
line
of the
oscilloscope
CRT
readout.
7-1
