R509 RES, 18.7, 1%, 125mW, METAL FILM R-391-18.7
R516, 523 RES, 4.02K, 1%, 100MW,, THICK FILM R-418-4.02K
R517, 539-541 RES, 12.1, 1%, 125MW METAL FILM R-391-12.1
R520 RES, 301, 1%, 100MW, THICK FILM R-418-301
R524, 538 RES, 12.1, 1%, 125MW METAL FILM R-391-12.1
R531 RES, 301, 1%, 100MW, THICK FILM R-418-301
R542, 543 RES,.5,5%,1W, METAL R-444-.5
R544-547, 292 RES, 100K, 1%, 100MW THICK FILM R-418-100K
R548 RES, 30.1K, 1%, 100MW, THICK FILM R-418-30.1K
R550, 435, 436 RES, 499, 1%, 100MW THICK FILM R-418-499
R555 RES, 7.32K, .1%, .125MW, THIN FILM R-456-7.32K
R556 RES, 42.7K, .1%, .125W,THIN FILM R-456-42.7K
R557 RES, 17.2K, .1%, .125W, THIN FILM R-456-17.2K
R559 RES, 1.5K, 1%, 100MW THICK FILM R-418-1.5K
R568, 574, 575 RES, 562K, 1%, 125MW, METAL FILM R-391-562K
R600, 449 RES, 100K, 1%, 100MW THICK FILM R-418-100K
R602, 607, 558 RES, 1.5K, 1%, 100MW THICK FILM R-418-1.5K
R609 RES NET TF-245
R610 RES, 1.28M, .1%, 1/8W METAL FILM R-176-1.28M
R611, 621 RES, 475, 1%, 100MW, THICK FILM R-418-475
R612 RES, 5.11K, 1%, 100MW, THICK FILM R-418-5.11K
R613, 624, 659, 660, RES, 100, 1%, 100MW, THICK FILM R-418-100
518, 519
R614, 615, 208, 553, 554 RES, 2.21K, 1%, 100MW, THICK FILM R-418-2.21K
R618 RES, 34K, 1%, 100MW, THICK FILM R-418-34K
R619 RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R620 RES, 82.5, 1%, 100MW, THICK FILM R-418-82.5
R623, 154, 155 RES, 10, 10%, 100MW, THICK FILM R-418-10
R650 ,651 RES NET, 9K-1K, MICRO DIVIDER TF-246-2
R652, 665 RES, 357, 1%, 100MW, THICK FILM R-418-357
R656 RES, 8,98K, .1%,.125W THIN FILM R-456-8.98K
R657, 658 RES, 1M, 1%, 100MW, THICK FILM R-418-1M
R666 RES NET, 3K, 12K, 0.1%, 100MW THIN-
FILM
TF-237-2
RT200 POLYSWITCH, PTC RESISTOR RT-17
T500 TRANSFORMER TR-311A
TP200-215, 218-225, 227,
2
28
, 230-235, 500
CONN,TEST POINT CS-553
TP501, 506-510 CONN,TEST POINT CS-553
U201, 212, 214, 230, 241, IC, CMOS ANAL SWITCH, DG444DY IC-866
400-406, 652
U202, 650, 203 IC, OP AMP LT1112 IC-1048
Table 6-1 (cont.)
A
n
alog board parts list
Circuit designation Description Keithley part no.
Replaceable Parts 6-9
2410-902-01.book Page 9 Monday, November 7, 2005 2:49 PM
