U204, 229 IC, 8-CHAN ANA MULTI-
PLEXER,DG408DY
IC-844
U205, 407 IC, HEX INVERTERS, 74HC400 IC-880
U209, 215 IC, QUAD COMPARATOR,LM339D IC-774
U210, 220 IC, DUAL BIPOLAR OP-AMP, LT1124CS8 IC-955
U211, 213 IC, BIFET OP AMP, AD712JR IC-834
U221, 227 IC, DIFF. AMP, AMP03GP IC-988
U222 IC, OP-AMP, LTC1050CS8 IC-791
U223, 409, 237 IC, MOSFET DRIVER, TLP591B IC-877
U226, 659 IC, 20V OP-AMP, LT1097S8 IC-767
U231, 219, 235, 234, IC, OP AMP, LOW POWER AD795JR IC-1052
262, 232
U238 IC, CMOS ANA SWITCH SPST
MAX3
26
CSE
IC-909
U239 IC, QUAD 2-INPUT NAND, 74HC00M IC-781
U240 IC,POS NAND GATES/INVERT,74HCT14 IC-656
U242-247 IC,DUAL HIGH CMR/SPEED
OPTO,
H
CPL-2631
IC-588
U252-256 IC 8 STAGE SHIFT CD74HC4094M IC-1026
U257 IC, SUPPLY VOLT SUPERVI-
SOR,TL7705A
IC-860
U263, 228 IC, OP-AMP, LOW NOISE LT1007CS8 IC-949
U265 IC, PHOTO TRANS, TLP626BV-LFI IC-1006
U408, 218, 216, 225 ICM DUAL J-FET OP-AMP, OP-282GS IC-968
U500 IC, OP-AMP, AD847JN IC-890
U501 IC, VOLT COMPARATOR LM393D IC-775
U502 PROGRAMMABLE TEMP CONTROLLER IC-1062
U600, 264, 206, 207, IC, DUAL PICOAMP OP-AMP AD706JR IC-910
208, 233
U601 IC,QUAD D FLIP FLOP W/CLK,RESET
74HC175 IC-923
U604 IC, NCHAN LAT DMOS QUADFET,
S
D
5400CY
IC-893
U605 INTEGRATED CIRCUIT, OPA177GS IC-690
U606, 236 IC, HI-SPEED BIFET OP-AMP, AD711JR IC-894
U607 IC, OP-AMP, NE5534D IC-802
U608 IC, VOLT. COMPARATOR,LM311M IC-776
U609 PROGRAMMED IC 2400-801-*
U651, 602, 603, 224 IC, QUAD 2 IN NOR, 74HCT02 IC-809
U660, 661 IC, 16 BIT DAC, AD7849BR IC-1004
VR200, 201 DIODE, ZENER MM524694 DZ-113
VR214, 215, 504, 505, 506 DIODE, ZENER, 8.2V, MMBZ5237 DZ-92
VR216, 217, 650, 651 DIODE, ZENER 17V, MMBZ5247BL DZ-104
Table 6-1 (cont.)
A
n
alog board parts list
Circuit designation Description Keithley part no.
6-10 Replaceable Parts
2410-902-01.book Page 10 Monday, November 7, 2005 2:49 PM
