ii
Figure 1:ăContents of Shipping Box 3............................
Figure 2:ăDimensional Drawing of a Rack Adapted Instrument 4.....
Figure 3:ăRemoving the Power Cord 5............................
Figure 4:ăRemoving the Rear Cover 6............................
Figure 5:ăRemoving the Cabinet 7...............................
Figure 6:ăRemoving the Handle and Front Feet 8..................
Figure 7:ăPreparing the Rack Adapter for the Instrument 9..........
Figure 8:ăInsert the Rear Cover 10................................
Figure 9:ăInsert the Instrument Cabinet into Rack Adapter 11.........
Figure 10:ăInstrument Cabinet and Rear Cover Installed 12...........
Figure 11:ăInstall the Front Support Brackets 13....................
Figure 12:ăSecure the Instrument to the Rack Adapter 14............
Figure 13:ăRemoval of Swivel Retaining Screws 15..................
Figure 14:ăInstalling BNC Connectors 18..........................
Figure 15:ăNylon Channels Installed in the Rear Support 19..........
Figure 16:ăFront Panel Cabling 20................................
Figure 17:ăSlideĆOut Tracks 22...................................
Figure 18:ăLocating Mounting Holes for the Stationary Sections 23....
Figure 19:ăAttaching the SlideĆOut Tracks in Front of the
Equipment Rack Rails 24.....................................
Figure 20:ăAttaching the SlideĆOut Tracks Behind the
Equipment Rack Rails 24.....................................
Figure 21:ăAttaching the Support Pin 26...........................
Figure 22:ăAttach the Angle Brackets to the SlideĆOut Tracks 27......
Figure 23:ăAttach the Support Blocks 28...........................
Figure 24:ăMating the Support Pin with the Adapted Instrument 29....
Figure 25:ăAdding the Spacer to the Rear Support 30...............
Figure 26:ăAttaching Extension Brackets 32........................
Figure 27:ăTrack Alignment 33....................................
Figure 28:ăSecure the Rack Adapter to the Equipment Rack 34.......
Figure 29:ăExploded View of Rack Adapter 39......................
