016Ć0096Ć00 Rear Support Kit

016Ć0099Ć00 Hardware Kit

BNC Connectors

Hardware Bag

Bar Nuts and

Front Panel

Screws

Rear Cover

Retaining Screws

Two Extension

Brackets

Left and Right

SlideĆout Track

Assemblies

SlideĆout Track

Assemblies Box

    

Table of Contents3
Safety Summary5
General Information7
Description7
Electrical and Environmental Characteristics7
Clearance Requirements7
Equipment List8
Figure 1: Contents of Shipping Box9
Figure 2: Dimensional Drawing of a Rack Adapted Instrument10
Attaching the Rack Adapter11
Preparing the Instrument11
Figure 3: Removing the Power Cord11
Figure 4: Removing the Rear Cover12
Figure 5: Removing the Cabinet13
Installing the Instrument into the Rack Adapter14
Figure 6: Removing the Handle and Front Feet14
Figure 7: Preparing the Rack Adapter for the Instrument15
Figure 8: Insert the Rear Cover16
Figure 9: Insert the Instrument Cabinet into Rack Adapter17
Figure 10: Instrument Cabinet and Rear Cover Installed18
Figure 11: Install the Front Support Brackets19
Figure 12: Secure the Instrument to the Rack Adapter20
Figure 13: Removal of Swivel Retaining Screws21
Attaching BNC Cables23
Rear Panel Cabling24
Figure 14: Installing BNC Connectors24
Figure 15: Nylon Channels Installed in the Rear Support25
Front Panel Cabling26
Figure 16: Front Panel Cabling26
Installation into the Equipment Rack27
Attach the Front Ends of the Slide out Tracks28
Figure 17: Slide out Tracks28
Figure 18: Locating Mounting Holes for the Stationary Sections29
Figure 19: Attaching the Slide out Tracks in Front of the Equipment Rack Rails30
Figure 20: Attaching the Slide out Tracks Behind the Equipment Rack Rails30
Attach the Rear Ends of the Tracks31
19 Inch Standard Cabinet Installation32
Figure 21: Attaching the Support Pin32
Figure 22: Attach the Angle Brackets to the Slide out Tracks33
Figure 23: Attach the Support Blocks34
Figure 24: Mating the Support Pin with the Adapted Instrument35
Figure 25: Adding the Spacer to the Rear Support36
14 To 26 Inch Cabinet Installation37
Figure 26: Attaching Extension Brackets38
Track Alignment39
Figure 27: Track Alignment39
Final Installation40
Figure 28: Secure the Rack Adapter to the Equipment Rack40
Replaceable Parts41
Parts Ordering Information41
Using the Replaceable Parts List42
Figure 29: Exploded View of Rack Adapter45
