Model 880 DEPOSITION CONTROLLER
y
SECTION 3.XX
e page 131 of 275 ^
Communications setup includes:
COM/IO lock code
KEYBOARD BEEP
RS232 Baud rate
RS232 Protocol
To view / program one of these...
Screen Key[s] to press
Run Time fixed MENU
MAIN MENU EXECUTIVE MENU
EXECUTIVE MENU COMM. SETUP
COMMUNICATIONS SETUP MENU arrow[s] ; EDT (edit)
( Lock Code, if enabled [see Comm Setup] numeric entry + ENT (enter) )
COMMUNICATIONS SETUP EDIT MENU arrow[s] ; CHG (change)
COMMUNICATIONS SETUP EDIT/CHG
MENU
numeric entry[s] + ENT (enter)
System Configuration includes:
LCD Contrast / Bias
Password Lock #
(Process) Run Number
Recorder Function
Recorder Out Channel
Real Clock Time
Real Clock Date
Need Source/Sensor Card 1
Need Source/Sensor Card 2
Need Source/Sensor Card 3
Need Source/Sensor Card 4
I/O Slot 1 Type
I/O Slot 2 Type
I/O Slot 3 Type
I/O Slot 4 Type
Memory Module IFC
To view / program one of these...
Screen Key[s] to press
Run Time fixed MENU
MAIN MENU EXECUTIVE MENU
EXECUTIVE MENU SYSTEM CONFIG
System Configuration menu arrow[s] + EDT (edit)
( Lock Code, if enabled [see Sys Config] numeric entry + ENT (enter) )
System Configuration Edit menu arrow[s] + CHG (change)
System Configuration Edit/Change menu numeric entry + ENT (enter)
