BRAVO – Wireless Alarm Control Panel
39
10. Replacing Batteries
10.1. Replacing the Panel Battery
ATTENTION: Use only Li-Po batteries supplied
by the manufacturer, with parameters 3,7V/
4000mAh and max. size 80х65х10mm!
To replace the battery with new:
 Switch off the mains power supply of the panel.
 Undo the two screws fixing the front panel to the
bottom. The cover must be closed.
 Switch off the battery – set the dip-switch “Battery” in
“OFF” position.
 Switch off the “Battery” connector from the terminal.
 Remove the cover of the battery.
 Replace the battery with new. Run the cable with
connector through the side opening of the cover.
Mount the battery cover back on its place.
 Switch on the “Battery” connector to the terminal and
set the dip-switch “Battery” in “ON” position.
 Close the box and switch on the mains power supply
of the panel.
 Set the internal clock with ProsTE software.
10.2. Detectors (PIR, MC, FL, FD)
ATTENTION: Use only battery approved by the
manufacturer, type CR123A 3V/ 1500mAh!
To replace the battery with new:
 Remove the cover of the detector’s enclosure.
 Remove the battery (two batteries in BRAVO FD).
 Press button ENROLL on the PCB. Wait for 10-15
seconds and place the new battery, as observe the
polarity. The LED lights in sequence in red, then in
green.
 Mount back the cover of the device enclosure.
10.3. Key Fob
ATTENTION: Use only battery approved by the
manufacturer, type CR2450 3V/600mAh!
To replace the battery with new:
 Remove the cover of the key fob.
 Remove the battery.
 Place the new battery, as observe the polarity.
10.4. Outdoor sounder
ATTENTION: Use only battery pack approved by
the manufacturer – 3x3V/ 15Ah, CR34615 type,
size D!
To replace the battery pack with new:
 Remove the sounder covers to access the PCB.
 Switch off the connector of the battery pack and
dismount it from the plastic bottom.
 Press button ENROLL on the PCB. Wait for 10-15
seconds and switch on the connector of the new
battery pack, as observe the polarity. The LED will
light first in red and then continuously in green.
 Mount the covers back on their places.
As option, the outdoor sounder BRAVO SR can be
powered on with adapter 12VDC/1A. The prepared
wires of the adapter are connected to the terminals
+12V and GND on the PCB with strictly observing the
polarity.
Attention: The connection of the optional adapter
for power on of BRAVO SR must be performed
from a qualified electrician only!
Tips & Tricks...
 Bypass the device before replacing its battery so to
eliminate the tamper signalization from the panel.
 The battery life can be increased if the LED
indication of devices is disabled – set the dip-switch
1 in position “ON”.
Environmental Protection
Directive of batteries disposal –
Information for the user (2013/56/ЕО)
The used batteries from devices after changing with
new should not be disposed together with other
household waste. The chemical elements, used in the
batteries can seriously harm the man’s health and the
outdoor environment.
The recycling of the used batteries and waste of
batteries contributes for protection, keeping clean and
improving the outdoor environment
MAINTENANCE
